BSS110

Cove BSS110

Adjustable cove mount LED luminaire

CutsheetExplore Cove

Downloads

Features

The BSS110 is a small profile, linear LED fixture for cove mount applications. The sheet formed and extruded components combine to produce a rugged, functional and simple luminaire. The unique rotating element allows for 120° range of focus adjustment and positive locking that is easily performed in the field. The BSS110 is fitted with 90+ CRI LEDs and available with two lens optics.

Available for QuickShip.

Performance

  • Nominal Length: 4'
  • Output: L: low | R: regular
  • Asymmetric | Lumens/ft.: L: 485 | R: 655
  • Asymmetric | Watts/ft.: L: 5.5 | R: 7.6
  • Asymmetric | Luminaire Lumens: L: 1838 | R: 2477
  • Asymmetric | Efficacy (LPW): L: 89 | R: 86
  • Frosted | Lumens/ft.: L: 465 | R: 625
  • Frosted | Watts/ft.: L: 5.6 | R: 7.7
  • Frosted | Luminaire Lumens: L: 1753 | R: 2362
  • Frosted | Efficacy (LPW): L: 83 | R: 81

Note: All data reflects fixtures with 3500K LEDs

Lens Options

Asymmetric Optic

Asymmetric light distribution

Ordering Code: A

Frosted Optic

Lambertian light distribution

Ordering Code: F

Specifications

Fixture mounting/wiring channel is formed and welded 20 ga. steel chemically treated to resist corrosion and enhance paint adhesion

LED housing is extruded aluminum with sheet aluminum end caps

Standard fixture finish is semi-gloss white powder coat, applied post production

Asymmetric and general diffuse extruded acrylic lens options available

Available in nominal lengths of 2’, 3’, 4’ and 5’

LED housing rotates and locks in place without tools at -15°, 0°, 15°, 30°, 45°, 60°, 75°, 90° and 105°

Knock outs on ends, and underside accept standard electrical fittings by others

Standard integral 120V-277V driver offered with 0-10V dimming or non-dim (other dimming driver options available)

Integral 120-277V emergency battery backup available for 4’ nominal non-dim or 0-10V (consult factory for all other lengths/drivers)

Standard outputs range from 465 to 655 lumens per foot, dependent on optic option

LEDs available in 2700K, 3000K, 3500K, and 4000K, within a 3 step MacAdam ellipse, all with 90+ CRI typical

Life: 50,000 hours L70

Limited five year warranty

UL and C-UL listed for dry and damp locations

IBEW manufactured and assembled

Made in U.S.A.

Product Data

Nominal Fixture Length

  • 2: 23-3/32”
  • 3: 34-9/32”
  • 4: 45-15/32”
  • 5: 56-23/32”

Correlated Color Temperature

  • 27: 2700K - 90+ CRI
  • 30: 3000K - 90+ CRI
  • 35: 3500K - 90+ CRI
  • 40: 4000K - 90+ CRI

Driver

  • ND: non-dimming
  • 347: 347V non-dimming
  • DM: 0-10V, 1%
  • HES: Lutron EcoSystem, soft-on/fade-to-black, 1%
  • H2: Lutron Hi-lume 2-wire forward phase, 1%, (120V ONLY)
  • E5: Lutron EcoSystem 5-Series, 5%
  • EL: eldoLED ECOdrive 0-10V, 1%

Light Output

(lumens per foot w/ optic option A)

  • L: low – 485
  • R: regular – 655
  • CF: consult factory for custom output

Options

  • ED: emergency driver (4’ nom. non-dim or 0-10V only)

Optic

  • A: asymmetric
  • F: frosted (Lambertian)

Section

Shown with frosted optic
