BFL250

Single lamp T8, remote ballast

Cutsheet

Downloads

Features

Even with the broadening market adoption of solid state lighting, the linear fluorescent lamp is still a relevant source for many applications. Bartco Lighting offers dozens of linear T5 and T8 models from miniature, remote ballast profiles to versatile, multi-lamp strips.

Specifications

  • Fully assembled housing is formed, 20 ga. steel, chemically treated to resist corrosion and enhance paint adhesion
  • Standard finish is high reflectance white powder coat, applied post production
  • Installed end feed connector accepts 3/8″ steel flex conduit (available separately)
  • Wired with 12′ leads for instant start ballast operation
  • Easy mounting through provided holes in housing
  • Available for T8 13W, 14W, 15W, 17W, 25W, 32W or 40W linear fluorescent lamp in single and tandem lamp models
  • UL and ULC listed for dry and damp locations
  • Requires a remote ballast and enclosure (ordered separately)
  • IBEW manufactured and labeled
  • Made in the U.S.A.

NOTE: Lamp holders are wired for instant start ballasts. For rapid start wiring, add suffix “/RS” to catalog number.
